TruckHouse
TruckHouse BCR
Carbon fiber composite on AEV Prospector XL
Starting At
$475,000
Chassis
RAM 3500 AEV Prospector XL Crew Cab 4x4
Battery
10.2 kWh
Solar
600W
Fresh Water
42 gal
Sleeps
2
GVWR
14,000 lbs
Wet Bath
Yes — Indoor
Best For
- International travel (smallest/lightest Class 4)
- Maximum maneuverability
- Buyers who prioritize trail capability over living space
Strengths
- Smallest and lightest in comparison — best for trails and international
- Carbon fiber monocoque shell
- AEV Prospector XL is a proven platform
- 48V electrical system
- Heated floors standard
- RAM 3500 Cummins — most powerful drivetrain (370 HP / 850 lb-ft)
Considerations
- Smallest living space and water capacity (42 gal)
- 10.2 kWh battery — lowest in class
- 600W solar — moderate
- Sleeps 2 only
- 52 gal fuel tank limits range
- Driving height not officially published
Full Specifications
| MSRP | $475,000 |
|---|---|
| Fully Loaded Estimate | $600,000 |
| Adventure Ready Price | Not published |
| Price Includes Truck | Yes |
| Deposit Required | Contact manufacturer |
| Estimated Lead Time | 12-18 months |
| Build Type | Turnkey |
| Build Approach | Factory-built on AEV Prospector XL chassis |
| Sales Channel | Factory direct (TruckHouse) |
| Base Chassis | RAM 3500 AEV Prospector XL Crew Cab 4x4 |
|---|---|
| Chassis Class | Class 4 |
| Engine | 6.7L Cummins I6 Turbo Diesel |
| Horsepower | 370 HP |
| Torque | 850 lb-ft |
| Transmission | 6-speed automatic (Aisin) |
| Drivetrain | 4x4, selectable |
| Fuel Type | Diesel |
| Fuel Capacity | 52 gal |
| Estimated Range | Not published |
| GVWR | 14,000 lbs |
| Towing Capacity | Not published |
| Hitch / Receiver | 2.5" receiver |
| Suspension | AEV DualSport suspension with Bilstein 5100 shocks |
| Tires | 37" BFGoodrich KM3 (super single rear) |
| Wheels | AEV Salta wheels |
| Super Singles | Yes |
| Onboard Air | Standard |
| Exterior Driving Height | ~10'6" (est.) |
|---|---|
| Interior Standing Height | 6'2" |
| Ground Clearance | Not published |
| Approach Angle | Not published |
| Departure Angle | Not published |
| Overall Length | 22'6" |
| Exterior Width | 7'6" |
| Wheelbase | 169.5" |
| Interior Square Footage | Not published |
| Kitchen Aisle Width | Not published |
| Shower / Wet Bath Height | Not published |
| Bunk Headroom | Not published |
| Curb Weight | 12,500 lbs |
| Payload Capacity | 1,500 lbs |
| System Voltage | 48v |
|---|---|
| Solar | 600W |
| Solar Details | 600W roof-mounted rigid panels |
| Battery (kWh) | 10.2 kWh |
| Battery (Ah) | Not published |
| Battery Details | 10.2 kWh @ 48V LiFePO4 |
| Inverter | 3,000W |
| Inverter Details | 3,000W Victron inverter/charger |
| Charging Sources | Solar (600W) Alternator (DC-DC) Shore power |
| Shore Power | 30A shore power |
| Control System | Victron monitoring system |
| Fresh Water | 42 gal |
|---|---|
| Grey Water | 20 gal |
| Black Water | Not published |
| Toilet | Thetford cassette |
| Hot Water | Diesel hydronic |
| Filtration | Standard filtration |
| Wet Bath | Yes — Indoor |
| Exterior Shower | Hot/cold exterior rinse |
| Winterization | 4-season rated |
| Heating System | Espar diesel hydronic (in-floor) |
|---|---|
| Air Conditioning | Dometic rooftop A/C |
| Heated Floors | Standard |
| Ventilation | MaxxAir fans |
| Cooktop | 2-burner induction |
|---|---|
| Oven / Microwave | Convection microwave |
| Refrigerator | Large 12V compressor fridge/freezer |
| Sink | Undermount stainless |
| Countertop | Solid surface |
| Pantry / Storage | Overhead and under-counter |
| Primary Bed | Queen cabover (60" × 80") |
|---|---|
| Bed Size | Queen |
| Secondary Sleeping | Dinette converts |
| Sleeps | 2 |
| Rooftop Tent | N/A |
| Shell Material | Carbon fiber composite monocoque |
|---|---|
| Exterior Coating | Not published |
| Insulation | Closed-cell spray foam |
| Front Bumper | AEV front bumper |
| Rear Bumper | AEV rear bumper with swing-outs |
| Light Bar | LED roof-mounted |
| Front Winch | Warn front winch |
| Rear Winch | Not published |
| Awning | Manual awning |
| Exterior Storage | Under-body storage |
| Entry Door | Insulated entry door |
| Spare Tire | Swing-out carrier (AEV rear bumper) |
| Starlink | Not published |
| Windows | Dual-pane insulated |
| Roof Hatch | Standard |
| Cab Pass-Through | Standard pass-through |
| Color Options | Limited custom options |
|---|---|
| Cabinetry | Custom cabinetry |
| Flooring | Heated flooring |
| Walls / Ceiling | Finished interior panels |
| Table / Dining | Convertible dinette |
| Closet | Not published |
| TV / Display | Not published |
| Audio System | Bluetooth audio |
| Builder Warranty | TruckHouse structural warranty |
|---|---|
| Chassis Warranty | RAM 3yr/36,000 mi |
| Powertrain Warranty | RAM 5yr/100,000 mi drivetrain |
| Smoke / CO Detector | Standard |
| Fire Extinguisher | Standard |
